Finished Products
-
Product Parameters
Model：YK-5
Hydraulic oil: 46# hydraulic oil
Production speed: 2-3 PCS/min
Diameter range: 120-400mm
Screen height: 200-660mm
Total power: 8 kW
Gas pressure: 0.6 mpa
Power supply: 380V/ 50Hz
Dimensions: 1800mm*1750mm*1880mm (1050KG)
700mm*650mm*1300mm (220KG)
The operation is simple, enter the circumference on the screen
-
Product Features
High precision: The size and shape of the bite can be accurately controlled to ensure that the width, depth and angle errors of the bite are within a very small range, meeting the high-precision requirements of large air filter production and ensuring that the connections between the filter components are tight and well sealed.
High efficiency: The advanced transmission system and control system can realize fast bite processing, process a large number of plates per hour, improve production efficiency and meet the needs of large-scale production.
Good stability: The machine body structure is solid, the transmission system is stable and reliable, and it is not easy to fail during long-term continuous operation, ensuring the continuity and stability of production.
Strong adaptability: Different bite molds can be replaced according to different large air filter production needs to achieve bite processing of various shapes and specifications. It is suitable for various types of metal plates, such as galvanized plates, aluminum plates, etc.
-
Application
Used in the production of truck air filters
-
