Auto Horizontal Multi-layers Steel Clipping Machine

Model：JT-500

Production capacity: 6 PCS/min

Filter paper height: 50-500mm

Steel strip specification: thickness 0.25-0.3mm width 16m

Motor power: 1.1KW

Power supply voltage: 380V/50HZ

Machine weight: 400kg

Overall size: 1500*800*1200mm

1.Ensure clamping accuracy: The use of sophisticated mechanical structure and pneumatic/hydraulic drive system can accurately control the position, force and angle of the clamp, ensuring the consistent fit between the clamp and the hydraulic oil filter, effectively avoiding product quality fluctuations caused by manual operation errors and improving product qualification rate.

2.Adapt to diverse products: By replacing fixtures of different specifications or adjusting equipment parameters, it can quickly adapt to the iron clamping needs of hydraulic oil filters of different models and sizes. It has strong flexible production capabilities, reduces equipment replacement and debugging time, and improves the flexibility of the production line.

3.Easy to integrate and manage: It can be seamlessly connected with other equipment in the hydraulic oil filter production line (such as conveyor lines, testing equipment, etc.) to form an automated production process.

The production line is applied to auto tri-filter industry, hydraulic pressure, purification and water treatment industries, etc.
